Topic: My new eurovan  (Read 14436 times)

Offline dubtech

  • Hixson
  • Joined: Apr 2005
  • Posts: 251

Re: My new eurovan

« Reply #45 on: March 22, 2012, 08:33:53 PM »
And you guys thought I was crazy to make them move that stuff from the old shop...

I've still got the parts department's old microfiche readers too.  Most of the microfiche is in pretty sad shape and the bulb is shot in the one that still has the glass in it, lol.

Offline travisyoung

Re: My new eurovan

« Reply #46 on: March 22, 2012, 09:37:02 PM »
I bet the 1551 hasn't been fired up since before we moved,  cool that it still works and I found the adapter

Offline Ret.Bugtech

Re: My new eurovan

« Reply #47 on: March 23, 2012, 08:01:29 AM »
 Dang !!!  Now I know why I retired when I did.  :o ::)   Move over Zen  ;D ;D

Offline certdubtech

  • In the Garage...
  • Joined: May 2006
  • Posts: 3199

Re: My new eurovan

« Reply #48 on: March 24, 2012, 11:10:03 AM »
This pic was taken of Travis using the 1551 Scan tool...



 :P

 :D :D

Offline Ret.Bugtech

Re: My new eurovan

« Reply #49 on: March 24, 2012, 11:34:23 AM »
Funny as heck ;D ;D ;D     For a minute there , I thought it was a self -portrait of you with Big hair trying to start a Type-4 after beating all the valve seats back in the heads. ;D ;D

Offline travisyoung

Re: My new eurovan

« Reply #50 on: March 27, 2012, 01:48:42 PM »

Offline travisyoung

Re: My new eurovan

« Reply #51 on: March 28, 2012, 09:02:50 PM »
Check the wiring to the trans,  I have 65 ohms at all of the solenoids from the trans module plug with the harness plugged in at the trans,  I have not seen any wires shorted together ,  I have no resistance on the   Temp sensor?

Offline travisyoung

Re: My new eurovan

« Reply #52 on: March 28, 2012, 09:04:14 PM »
Put the Yakima basket up top

Offline ASBug

  • Varnel, Ga
  • Joined: Jan 2008
  • Posts: 3032

Re: My new eurovan

« Reply #53 on: March 28, 2012, 10:30:33 PM »
Funny as heck ;D ;D ;D     For a minute there , I thought it was a self -portrait of you with Big hair trying to start a Type-4 after beating all the valve seats back in the heads. ;D ;D
No, that is him just lapping the valves!
KC

Offline travisyoung

Re: My new eurovan

« Reply #54 on: April 04, 2012, 04:55:36 PM »
Summoning the powers of dubtech,  I need some help with the euro van,  could the shorted wires in the harness have toasted the Tcm or solenoids,  do I have a bad solenoid foil strip?

Offline dubtech

  • Hixson
  • Joined: Apr 2005
  • Posts: 251

Re: My new eurovan

« Reply #55 on: April 04, 2012, 09:20:15 PM »
Check the wiring to the trans,  I have 65 ohms at all of the solenoids from the trans module plug with the harness plugged in at the trans,  I have not seen any wires shorted together ,  I have no resistance on the   Temp sensor?

Plug everything back in and see what the TCM thinks the fluid temperature is when the engine is cold.  If the TCM thinks the fluid temp is maxed out then it's a good possibility that the temp sensor is bad. It's a negative temperature coefficient sensor so as the fluid temp rises the resistance goes down.  The temp sensors weren't exactly what you'd call "robust" and you get a free valve body conductor strip when you buy the sensor so...

If you do end up replacing the conductor strip be sure to use the special tool that looks kind of like a tuning fork to disconnect the plugs from the solenoids.  It's really easy to break the connector on the solenoid if you just try to use a screwdriver.

P.S.  Don't get one off Craigslist, the walk to the parts department isn't _that_ far   ;)

Offline travisyoung

Re: My new eurovan

« Reply #56 on: April 05, 2012, 07:23:07 AM »
Cool,  thanks I will check that

Offline certdubtech

  • In the Garage...
  • Joined: May 2006
  • Posts: 3199

Re: My new eurovan

« Reply #57 on: April 05, 2012, 01:56:02 PM »


P.S.  Don't get one off Craigslist, the walk to the parts department isn't _that_ far   ;)

Am I the only one who laughed out  loud when they read that part?

 :D

Offline travisyoung

Re: My new eurovan

« Reply #58 on: April 05, 2012, 09:52:13 PM »
I checked MVb 1 to 5 in 5 there was a temp reading and it jumped around at 92 to 112 degrees,  I was thinking that there was a way to activate the solenoids with the scan tool

Offline dubtech

  • Hixson
  • Joined: Apr 2005
  • Posts: 251

Re: My new eurovan

« Reply #59 on: April 06, 2012, 05:02:35 AM »
So with the engine cold the temp reading was 92 to 112?  If so, that sounds like a problem since the TCM reads in Celsius.  As far as activating the solenoids you can try running output diagnostic test mode on the TCM and see if there's something there.

Also, there should be a special tool that hooks up between the transmission and the TCM that has lights on it so you can visually check the signals coming from the TCM.  See if you can find it and dig it out of the tool room.
